Normative design standards

The design specifications of the system equipment implement the requirements of the current design specifications and also comply with the requirements of the design specifications generally implemented at present.

Standards used for all mechanical equipment conform to GB/T standards and ISO standards.

The standards used for all electrical equipment are in accordance with IEC standards and GB/T standards.

​

Advantages of surface treatment

All metal parts are treated by electroplating, galvanizing or oxidizing processes to ensure a bright surface, uniform and smooth plating, no stains, blisters and blobs, ensuring that all parts are rust-free, beautiful and corrosion-resistant.

Metal rollers are wear-resistant without deformation, discoloration and rusting.

Good glossiness of aluminum parts and long service life.

​

Painting process

The following painting process is used for the parts of the body, wall plate and frame, shroud, etc.

Pretreatment: shot blasting Primer: epoxy zinc-rich primer

Intermediate paint: iron red epoxy thick paste general primer

Topcoat: Acrylic polyurethane topcoat

Dry film thickness: 80um

The coating is firm and protects the parts from rusting, corrosion resistance and beautiful color.


CE safety assurance measures

GPPE automatic thermal paper slitting and packaging line tested by CE safety system standard.

All driving parts (gears, belts, etc.) and rotating parts of the slitting process are equipped with protective covers.

automatic control system with emergency stop button.

circuit design with reliable working components, having functions such as machine safety stop.

​

​

​

​

​
